INFRAPUNAVASTAANOTIN 8-KANAVAISELLA LED-TILAILMAISULLA

This wireless IR receiver allows you to control up to 40 pushbuttons in your home, as well as check the status of 8 lighting points so as to control your hidden consumption. In addition, the Logitech Harmony® allows to label and to display each pushbutton. Velbus and Logitech Harmony® Now you can operate your Velbus installation wirelessly with the Logitech Harmony®. Increase the user-friendliness of the VMB8IR by controlling each channel individually (using IR). Only configurable via PC!
Ominaisuudet:
IR remote control for the Velbus system • up to 40 channels • 8 channels feature an indication LED • controllable through a universal remote control from the Logitech Harmony® series • possibility to disable each channel so it won't react • configuration is saved after power failure
Tekniset tiedot:
2-wire communication for Velbus data and 2 wires for power • reaction time per channel settable between 0, 1, 2 or 3 seconds • transmission/receiving range: +/- 8m • required power voltage: 12...18VDC • consumption in stand-by: 20mA • max. consumption: 35mA • IR modulation system: RECS80 with pulse position • dimensions ( W x H x D): 22 x 46 x 43mm / 0.86 x 1.81 x 1.69"
