30 W SINGLE OUTPUT INDUSTRIAL DIN RAIL POWER SUPPLY 12 V 2 A
Ominaisuudet ultra slim design with 35 mm (2SU) width universal input 85-264 VAC (277 VAC operational) no load power consumption 95% dip 0.5 periods, 30% dip 25 periods - >95% interruptions 250... Lue lisää
Tarjoustuote!
48,60 €(Sis.alv)
38,73 €(alv 0%)
tai 10 kpl hintaan 34,50 € / kpl(Sis.alv)
- Tuotekoodi: HDR-30-12
- EAN: 4711287421674
- Takuu: 1 vuosi
- Paino: 0.14 kg
- Toimittajan saatavuus: 200 kpl
Tilaa kerralla useampi ja säästä!
| Määrä | Hinta á |
|---|---|
1kpl | 48,60 €/ kpl |
5kpl | 36,43 €/ kpl-12,17 €/ kpl |
10kpl | 34,50 €/ kpl-14,10 €/ kpl |
kpl
Ominaisuudet
ultra slim design with 35 mm (2SU) width
universal input 85-264 VAC (277 VAC operational)
no load power consumption <0.3 W
isolation class II
pass LPS (limited power source)
DC output voltage adjustable
protections: short circuit / overload / over voltage
cooling by free air convection (working temperature : -30 - +70°C)
DIN rail TS-35/7.5 or 15 mountable
over voltage category III
LED indicator power on
3 year warranty
[b]for professional use only[/b]
This device must be installed by a qualified person.
Tekniset tiedot
output:
DC voltage: 12 V
rated current: 2 A
current range: 0 - 2 A
rated power: 24 W
ripple & noise (max.): 120 mVp-p
voltage adj. range: 10.8 - 13.8 V
voltage tolerance: ± 1.0 %
line regulation: ± 1.0 %
load regulation: ± 1.0 %
setup, rise time: 500 ms, 50 ms / 230 VAC - 500 ms, 50 ms / 115 VAC at full load
hold up time (typ.): 30 ms / 230 VAC - 12 ms / 115 VAC at full load
input:
voltage range: 85-264 VAC (277 VAC operational) - 120-370 VDC (390 VDC operational)
frequency range: 47 - 63 Hz
efficiency (typ.): 88 %
ac current (typ.): 0.88 A / 115 VAC - 0.48 A / 230 VAC
inrush current (typ.): cold start 25 A / 115 VAC - 45 A / 230 VAC
protection:
overload:
105 - 160 % rated output power
protection type: constant current limiting, recovers automatically after fault condition is removed
overvoltage:
15 - 18 V
protection type: shut down output voltage, re-power on to recover
environment:
working temperature: -30 to +70 °C
working humidity: 20 to 90 % RH non-condensing
storage: -40 to +85 °C, 10 to 95% RH
temperature coefficient: ± 0.03 %/°C (0 - 50°C )
vibration: 10 - 500 Hz, 2G 10 min / 1 cycle, 60 min each along X, Y, Z axes; mounting: compliance to IEC60068-2-6
operating altitude: 2000 m
over voltage category: III, according to EN61558, EN50178, EN60664-1, EN62477-1, altitude up to 2000 meters
safety & EMC:
safety standards: UL60950-1, UL508, TUV EN61558-2-16, IEC60950-1 approved, design refer to TUV EN60950-1
withstand voltage: input to output: 4 kVAC
isolation resistance: input to output: 100 MOhm / 500 VDC / 25 °C / 70 % RH
EMC emission:
conducted: EN55032 (CISPR32) / Class B
radiated: EN55032 (CISPR32) / Class B
harmonic current: EN61000-3-2 / Class A
voltage flicker: EN61000-3-3
EMC immunity:
ESD: EN61000-4-2 / Level 3, 8KV air - Level 2, 4KV contact - criteria A
radiated susceptibility: EN61000-4-3 / Level 3 - criteria A
EFT/Burest: EN61000-4-4 / Level 3 - criteria A
surge: EN61000-4-5 / Level 4, 2KV/L-N - criteria A
conducted: EN61000-4-6 / Level 3 - criteria A
magnetic field: EN61000-4-8 / Level 4, criteria A
voltage dips and interruptions: EN61000-4-11 / >95% dip 0.5 periods, 30% dip 25 periods - >95% interruptions 250 periods
other:
MTBF: 968.1Kh, MIL-HDBK-217F (25 °C)
dimensions: 35 x 90 x 54.5 mm (w x h x d)
