WIMA MKS4 0,010uF 630V 10mm

Capacitors that meet strict requirements PCM 7.5 - 37.5mm. Metallised polyester film. WIMA capacitors have reliable internal end terminations. They use a simple concept : the wire makes electrical contact with the complete surface of the electrode, which ensures minimal inductance. This results in capacitors with a good attenuation and self-resonance (see technical data and graphs).
Ominaisuudet:

Tekniset tiedot:
pitch: 10mm • operating voltage (max.): 630V • capacitance: 0.010µF • dielectric material: polyethylene terephthalate film • capacitor electrodes: vacuum-deposited aluminium • encapsulation: flame-retardant plastic case, UL 94 V-0, with epoxy resin seal / colour : red / marking : black • test specifications: in accordance with CECC30400 and IEC 384-2 • testing category: 55/100/21 in accordance with IEC • test voltage: 1.6 Ur, 2 sec. • temperature range: -55°C to + 100°C • capacitance tolerances: ± 20% (± 10%)
