LAAJAKAISTAELEMENTTI VISATON FR 16 WP CL 100 V

Merivedenkestävä 16 cm (6.5"") musta laajakaistaelementti. Täysin muovikuorinen, johdot päälystetty silikonilla.
Käyttökohteet esim. ulkokaiutin, venekaiutin, terassikaiutin, saunakaiutin.
Soveltuu myös klooria sisältäviin tilouhin, esim. uimahalleihin.


Typical applications:
- indoor swimming pools

Attributes:
- 100 V transformer
- seawater proof
- suitable for chloric air
- functionally at low temperature according to EN 60068-2-1 (-40 °C; 96 h)
- up to the standards of the Germanischer Lloyd (requirements for electrical equipment / low temperature)
- Plastic: ASA (UL 94:HB; UV-/weather-proof)
- ball-resistant

*) IP protection class for front side when built into a sealed enclosure

Technical Data:
Transformer matching	6; 3; 1,5 W
Sound pressure level	94 dB (1 W/1 m) @ 3500 Hz
Frequency response	60–15000 Hz
Mean sound pressure level	86 dB (1 W/1 m)
Max. sound pressure level	93 dB (6 W/1 m)
Opening angle (-6 dB)	46°/4000 Hz
Excursion limit	6 mm
Magnetic induction	1,0 T
Magnetic flux	250 µWb
Height of front pole-plate	4 mm
Voice coil diameter	20 mm
Height of winding	6 mm
Cutout diameter	142 mm
Net weight	0,6 kg
Protective system	IP 65 *)
Temperature range	−40 ... 80 °C
